JORC
3402 A1 JORC KAPTIV-MD-AL G1/2 4.5 230VAC 16BAR (NO)
2 966,43
SEK
I lager
Kategorier:
Condensate drain
Manufacturer: JORC
Specifikationer
- Valve seal
- FPM
- Test function
- Yes
- Maintainable valve
- Yes
- Protection class
- IP65 (NEMA4)
- Supply voltage
- 230 VAC
- Max. compressor capacity
- 10 m³/min. (350 CFM)
- Medium temperature
- +1°C to +50°C
- Plug type (power and alarm)
- DIN 43650-B
- Valve opening [mm]
- 2
- Ambient temperature
- +1°C to +50°C
- Gehäuse - Werkstoff
- Corrosion-resistant aluminium, EP coating
- Integrated stainless steel strainer
- Yes
- Side inlet adapter
- Yes, optional
- Inlet height [mm]
- 74
- Bemerkung
- with alarm
- Outlet connection
- 1/4" BSP, with hose connection Brass adapter
- Valve type
- 2/2-way, direct controlled
- Inlet connection
- 1/2" BSP oder NPT
- Alarm
- Visual, LED indication – open contact
- Bemerkung
- Electronic condensate drain
- Weight [kg]
- 0,662
- Max. compressor capacity
- 45 litres of condensate per hour at 16 bar
- System pressure
- 0 - 16 bar (0 - 230 psi)
