7007 LS JORC AIR-SAVER-LS G2 230VAC 16bar

Specifikationer

System pressure

0 to 16 bar

Ambient temperature

+1°C to +50°C

Valve housing material

Brass valve, nickel-plated

Protection class

IP54 (NEMA13)

Manual override

Yes

Supply voltage

230 V

Medium temperature

+1°C to +100°C

Bemerkung

Energy saver for compressed air

Relay switch

230 VAC

Outlet connection

2" (BSP or NPT)

Inlet connection

2" (BSP oder NPT)

Duration of valve opening/closing

105 sec. (90 °)

Weight [kg]

4,887

Power consumption

Approx. 9 W during cycle rotation
